#31: ULP Series - The ULP Stack

How the ULP stack works and why you need to understand it to ensure production quality releases.

What We’ll Cover

• The RISC-V ULP Stack Spec
• ESP32 Implementation
• How to calculate your stack space
• A simple trick to monitor the stack
• An Ominous Warning

To see all of the changes made and working simply run git checkout lesson-6-end.

To follow along, run git checkout lesson-6 and follow the instructions below.

The RISC-V Stack Specification

I’m not going to bore you with large portions of the RISC-V spec. It’s great reading if you need something to put you to sleep. All we care about in this lesson is the stack and all I’m going to share are these few bits of information from the Calling Convention document.

In the standard RISC-V calling convention, the stack grows downward and the stack pointer is always kept 16-byte aligned.

The stack pointer sp points to the first argument not passed in a register.

The RISC-V calling convention passes arguments in registers when possible. Up to eight integer registers, a0–a7, and up to eight floating-point registers, fa0–fa7, are used for this purpose.

I HIGHLY recommend you stop here and take 20 minutes to read the RISC-V Calling convention doc I linked above. It’s only 3 pages long and is a treasure trove of data to help you understand how the stack works in your ULP program.

While the document mentions floating-point registers, recall that the RISC-V chip on the ESP32 is fixed point so registers fa0-fa7 won’t exist.

So the spec has taught us some really important things:

1. The stack grows downward in memory
2. The stack pointer is always kept 16-byte aligned
3. Hardware registers are used to hold function arguments instead of the stack where possible
4. The sp register points to the first argument NOT in a register i.e to the start of the stack frame

Number 3 was an important concept for me when I was first digging into this. It’s general knowledge that function arguments and local variables go on the stack. This, however, tells us that most simple functions with a couple of arguments don’t add any additional stack space because the arguments are stored in raw hardware registers. 🤯

Locals are still added to the stack but this is a great piece of information to know when it comes to optimizing your C code.

How The ESP32 Implements the Stack

The implementation is quite trivial and we’ve already seen it. I just didn’t call it out at the time. Back in Lesson….you guessed it, Lesson 4 we looked at the generic linker file ulp_riscv.ld provided by IDF. Here it is again for reference.

ENTRY(reset_vector)
MEMORY
{
    ram(RW) : ORIGIN = 0, LENGTH = 4096
}
SECTIONS
{
    . = ORIGIN(ram);
    .text :
    {
        *ulp_riscv_vectors.S.obj(.text.vectors)
        *(.text)
        *(.text*)
    } >ram
    .rodata ALIGN(4):
    {
        *(.rodata)
        *(.rodata*)
    } > ram
    .data ALIGN(4):
    {
        *(.data)
        *(.data*)
        *(.sdata)
        *(.sdata*)
    } > ram
    .bss ALIGN(4) :
    {
        *(.bss)
        *(.bss*)
        *(.sbss)
        *(.sbss*)
    } >ram
    __stack_top = ORIGIN(ram) + LENGTH(ram);
}

All the way at the very bottom we have __stack_top = ORIGIN(ram) + LENGTH(ram);. That creates the symbol for our stack pointer. It’s assigned the value of the origin of our ram memory space plus the length of that space. With our current menuconfig settings that means 4096 bytes. So our __stack_top symbol points to the very end of the ULP memory region.

This allows it to meet the RISC-V spec of growing downward (because it has no other direction to grow).

But how does the stack pointer get initialized? The linker file just defines the symbol. It doesn’t load any registers. That has to happen at runtime in the form of RISC-V assembly commands executed by the processor.

The stack initialization happens in the startup code which is also provided by ESP-IDF. To find the file we need to search for our entry routine mentioned in the linker file (reset_vector). Run the following.

grep -rnw ~/esp/idf/components/ -e reset_vector

The search will yield a few results but we are looking for assembly source code so something that ends in “.S”. That still gives us a couple of options, several of which refer to an “lp_core” in the path. This is for a different chip than the ESP32-S3 that we’re using so we’re going to open components/ulp/ulp_riscv/ulp_core/ulp_riscv_vectors.S. Remember, you can just Ctrl-click it in the VSCode terminal window and it will open in a new editor tab.

In that file we find the following:

/* The reset vector, jumps to startup code */
reset_vector:
	j __start

This is the function definition of reset_vector with a very helpful comment informing you that the single assembly instruction is a jump instruction to another function called __start. Let’s keep hunting. A trick for a lot of these assembly functions is that they are declared as .global [function name]. Knowing this can help us narrow our search.

 grep -rnw ~/esp/idf/components/ -e ".global __start"

This time we get a single file result so let’s open it up. It’s small enough we can put the entire file here.

#include "sdkconfig.h"
#include "ulp_riscv_interrupt_ops.h"

    .section .text
    .global __start

.type __start, %function
__start:
    /* setup the stack pointer */
    la sp, __stack_top

#if CONFIG_ULP_RISCV_INTERRUPT_ENABLE
    /* Enable interrupts globally */
    maskirq_insn(zero, zero)
#endif /* CONFIG_ULP_RISCV_INTERRUPT_ENABLE */

    /* Start ULP user code */
    call ulp_riscv_rescue_from_monitor
    call main
    call ulp_riscv_halt
loop:
    j loop
    .size __start, .-__start

As you can see, the very first instruction in the __start function is la sp, __stack_top. This is a RISC-V assembly instruction that says “load symbol addres”(la) of __stack_top into register sp which is the RISC-V ABI symbol name for the stack pointer.

A little further down you can also see call main which is how the ULP app starts executing the code you wrote in main.c. Pretty cool stuff. Now you know, at the assembly level, how we go from ULP processor startup to your C code. And we also see how the stack pointer gets initiatlized.

How Much Stack Space Do I Have?

A very important piece of information you need to know when writing ULP programs is how much stack space your program has. This is very easy to calculate.

[STACK SPACE] = [ULP RESERVED MEM] - [SIZE OF ALL LINKED SECTIONS] - 0x10(16 bytes for call to main)

You can use the ULP application map file to easily calculate this (Lesson 4 folks). For simplicity let’s consider the following condensed map file. By condensed, I mean it only includes the lines that show the address and size of the 4 sections along with the MEMORY section

MEMORY
{
    ram(RW) : ORIGIN = 0, LENGTH = 4096
}
SECTIONS
{
.text           0x00000000      0xcd0
...
.rodata         0x00000cd0      0x13c
...
.data
...
.bss            0x00000e18       0x48
...
}

To calculate your available stack size you take the total length of 4096 and convert it to hex which is 0x1000. Then you simply subtract the size of each section along with an additional 16 bytes to account for the mandatory call to your main function (“Can’t get around the old minimum wage, Mortimer” IYKYK).

Stack Space = 0x1000 - 0xcd0 - 0x13c - 0x48 = 0x1ac = 428 - 16 (call to main) = 412 bytes

Notice the .data section in this example is empty as it has no size or address specified.

Your main application has 412 bytes available for stack growth. If all of your function calls are simple with not a lot of local variables you can assume 16 bytes of growth per call depth. That means, in this scenario, your function call stack could go 412 / 16 = 25.75, rounded down, 25 call levels deep.

Knowing that can inform some decisions like whether or not to shrink or grow your total ULP memory allocation.

Monitoring the Stack

If you’ve written much code for the ESP32 you may have used a super nice helper function called uxTaskGetStackHighWaterMark. This lets you know, for a given main application task, the high water mark for the stack. The lower that number, the closer you have come to a stack overflow and a panic reset of your ESP32.

Knowing that information is extremely helpful in configuring your ESP32 task stack size during development to ensure you aren’t playing with fire once your firmware goes to production.

Unfortunately there isn’t an equivalent function we can call from our ULP application. No problem. we’re developers, let’s write one. Better yet, let’s do it in assembly. Sounds scary but it’s actually quite trivial as you’ll see in a moment.

All we are trying to do is get the value of the stack pointer and display it somehow. Well, from Lesson 4 (if you still haven’t gone through it at this point, you’re hopeless and are never going to understand this stuff. Stop being lazy and do Lesson 4!). Anyway, from Lesson 4 we know that we have access to the RISC-V RV32IMC instruction set so really we just need to know a couple of things.

1. How do I get the value of the stack pointer
2. How do I load that into a C variable

Here is the quick version. From the Calling Convention doc (linked above) we know that the stack pointer’s ABI register name is sp. Now we just need to figure out how to load the value in that register into a C variable. Well, also from the Calling Convention doc, we know that the return value of a function is always passed in register a0 if it will fit in 4 bytes, and in a combination of a0 and a1 if we need 16 bytes. Since all addressing in RISC-V is 32-bit, a0 is all we need to return the stack pointer value.

With this we can reword what we are trying to do. “I need to load the value of sp into a0 and call that function from my C code”.

Create a new file in the ulp folder called sp.S (.S is the typical file extension for assembly). In that file we are going to create an assembly function called getsp. If you aren’t an assembly wizard don’t worry. I created this by simply pattern-matching the things I saw while digging around earlier to find the startup code.

.section .text.sp

# Assembly function to get the value of the stack pointer
.global getsp
.type getsp, @function

getsp:
    add a0, sp, zero
    ret

.section .text.sp specifies the section this should be put in. This helps our linker file know that it needs to be added to our .text section.

We declare the function as global and as type @function and then we define it. It’s two lines of code; an add instruction and the return instruction.

There is probably a better way to do this but it was the easiest I could find having not much RISC-V assembly experience (translation: almost none). The add instruction will store into a0 (our return value by calling convention) the sum of sp and zero. zero is a special register in RISC-V that is, yep, the value 0. So we are adding zero to the stack pointer and then storing the result in a0 which means we’re just storing the value of sp in a0. (I couldn’t figure out how to do this with a load instruction).

Now we just need to tell the build system to build this code and make it available to the linker. That’s as easy as adding it to the source list in our CMakeLists.txt file in our main directory.

set(ulp_riscv_sources
    "ulp/main.c"
    "ulp/sp.S"
)

Now we can call it from our ULP program and store the result in a shared variable. Let’s write a function that gives us the low water mark of our ULP stack. In other words, let’s keep track of how low our stack address gets. See if you can write some code in main.c to store the ULP stack low water mark in a shared variable as well as the current stack pointer address. We could put this code in a function but that would distort the value because calling it will further decrease the stack address.

Here’s my version. I added two new shared variables. One for the current stack pointer address and one for the lowest address.

extern uint32_t getsp();
volatile uint32_t cur_stack_address;
volatile uint32_t min_stack_address;

The extern uint32_t getsp(); tells the compiler “This function exists, but is defined somewhere else. Where is of no importance to you young Padawan compiler, for the linker knows.”

Then I added this to the main function.

cur_stack_address = getsp();
if(cur_stack_address < min_stack_address || min_stack_address == 0) {
    min_stack_address = cur_stack_address;
}

Back up in the main application app_main we can add the following in our while loop to print out the stack pointer low water mark.

static uint32_t old_lwm = 0x1000; // The starting point of the stack
if(old_lwm != ulp_min_stack_address){
    old_lwm = ulp_min_stack_address;
    ESP_LOGI(TAG, "ULP Stack Pointer LWM: 0x%lx", ulp_min_stack_address);
}

Time to run it and see what happens. idf.py flash monitor

I (288) main: Normal boot, starting ULP program
I (288) main: ULP Loop Count: 0
I (298) main: Current Reading: 0.000000
I (298) main: ULP Stack Pointer LWM: 0xff0

That’s awesome!! Let’s think about this for a second. The stack pointer starts at address 0x1000. However, in the startup code we found above we see a call main which is a call to our main function. Well, when you call a function a new stack frame has to be added. There are no arguments and no locals in our main but, per spec, the stack pointer has to be 16-byte aligned so it will grow downward by a minimum of 16 bytes for each function call. So, in hex, the stack pointer started at 0x1000. main is one stack frame deep so it will subtract 16 bytes, 0x10 hex, from the stack pointer address. 0x1000 - 0x10 = 0xff0 which is exactly what we see!

From our main application we can now monitor the location of the stack pointer.

Beware of Stack Growth

So now you should have a pretty solid understanding of how the stack works in your ULP program. Every time you call a level deeper in your code, a minimum of 16n bytes is subtracted from the stack pointer. When that function returns, the stack pointer has 16n bytes added back to it. If your code has only a few functions and doesn’t have a lot of nested calls you probably won’t need much stack space.

However, if your code is more complex and starts to make a lot of nested function calls or, even worse, uses recursion, what prevents the stack from growing indefinitely? The answer is….nothing. Absolutely nothing prevents the stack from runaway growth in your ULP program. And that, friends, is what we will cover in the next lesson. (🎵🎵 ominous music plays 🎵🎵)
